Catoosa, Oklahoma Fabrication Services
The Matrix Service fabrication facility in Catoosa, OK, offers direct barge access to the Gulf of Mexico. Our relationships with dedicated trucking companies, freight handlers, LTL carriers, railroads, and barge companies streamline transport for any project. Read more below or download the brochure to read about our facility’s full capabilities.
OSHA VPP Star Designation
The Catoosa fabrication facility is one of only two heavy metal fabrication facilities in the U.S. to achieve OSHA’s VPP Star status. As OSHA’s highest designation, it indicates the facility’s proven success in:
- Management leadership and employee involvement
- Worksite analysis
- Hazard prevention and control
- Safety and health training
Receipt of this designation is a testament to our employees’ commitment to maintaining a world-class safety culture and focus on eliminating incidents altogether.
PRODUCT TYPES
Our fabrication facility in Catoosa produces products for projects across the United States and Canada. Browse our complete capabilities and specs below:
- Pressure vessels
- Towers
- Drums
|
- Shop fabricated tanks
- Component fabrication
- Piping
|
- Structural
- Skid modules
- Stacks
|
|
CERTIFICATIONS
- ASME U Stamp – division I pressure vessels and equipment
- ASME U2 Stamp – division II pressure vessels and equipment
- ASME S Stamp – power boilers
- ASME B31.3 – process piping
- API – shop fabricated tanks and components
- AWS – structural components
- In-house QA/QC – CWI, API 510, 570, 653, NBIC
ACCESSIBILITY
- Railspur: connection to Burlington, Northern and Southern Kansas and Oklahoma railroad
- Water access: barge capabilities at Port of Catoosa to Gulf of Mexico
BAY SIZE
- (1) 500′ x 100′ wide
- (1) 500′ x 50′ wide
- (2) 300′ x 60′ wide
ELECTRIC OVERHEAD DOOR SIZES
- (2) 28′ high x 28′ wide
- (2) 20′ high x 25′ wide
- (1) 20′ high x 15′ wide
- (1) 20′ high x 50′ wide
- (2) 30′ high x 25′ wide
- (1) 30′ high x 55′ wide
- (2) 20′ high x 20′ wide
- (2) 20′ high x 28′ wide
- (2) 18′ high x 16′ wide
FORKLIFTS
- (1) CAT 31,700# capacity; 8′ lg. forks
- (2) CAT 17,000# capacity; 8′ lg. forks
- (2) CAT 14,000# capacity; 8′ forks
- (2) CAT 8,000# capacity; 5′ forks
- (1) CAT 9,000# capacity; 5′ forks
- (1) CAT 4,000# capacity; 4′ forks
- (1) Standup reachlift 2,000# capacity
PLATE MOVERS
- (2) Shuttlelift 48,000# capacity mobile crane
PRESS BRAKE
- (1) Accurpress 713010-12: 130 ton; 10′ bed and 2′ horn
- (1) Dual Accurpress 500 ton x 16′ length
- (32′ total; 1,000 ton max)
| MATERIAL |
THICKNESS |
LENGTH |
DIE OPENING |
| A36 |
1/2″ |
30′ |
5″ |
| A36 |
3/8″ |
32′ |
5″ |
| A36 |
1/4″ |
32′ |
3″ |
| A572 Grade 50 |
1/2″ |
23′ |
5″ |
| A572 Grade 50 |
3/8″ |
32′ |
5″ |
| A572 Grade 50 |
1/4″ |
32′ |
3″ |
| A517 |
3/8″ |
10′ |
5″ |
| A517 |
1/4″ |
28′ |
3″ |
SHEAR
| THICKNESS |
WIDTH |
| (min) 18 GA |
(min) N/A |
| (max) 5/8″ |
(max) 12′ length |
ANGLE ROLL
- (1) Faccin angle roll
- (1) Montgomery angle roll
| THICKNESS |
WIDTH |
LENGTH |
| (min)3/16″ |
(min) 2″ x 2″ |
(min) 10′ |
| (max) 5/8″ |
(max) 6″ x 6″ |
(max) 60′ |
IRON WORKERS/PUNCH PRESSES
- (1) Megaworker (60) ton
- (2) Scotchman (65) ton
| Whitney (2) |
|
| THICKNESS |
HOLE SIZE |
| (min)3/18 GA |
(min) 0 |
| (max) 3/4″ |
(max) 1″ |
CUT-OFF SAWS
- (1) Hemsaw horizontal saw (12 3/4″ x 12 3/4″)
- (1) Hemsaw CNC vertical tilt saw (18″ x 24″)
- (1) Hemsaw horizontal saw (16″ x 24″)
- (1) Cold saw
- (1) HYDmech (28″ x 28″)
| THICKNESS |
WIDTH |
LENGTH |
| Band saw |
|
|
| (min) N/A |
(min) 0 |
(min) 0 |
| (max) 12″ |
(max) 28″ |
(max) 28″ |
| Cut-off saw |
|
|
| (min) 18 GA |
(min) 0 |
(min) 1/4″ |
| (max) 3″ |
(max) 3″ |
(max) 3″ |
BURNING MACHINES
- (2) 2013 Messer MPC 2000 Plasma bevel head burning machines with bevel angle change on the fly technology, Telesis Pin Stamp system, true – hole and 12′ x 40′ cutting dimensions on water table. (Plasma burning capacities through 3 3/16″).
- (1) 2003 Alltra Plasma burning equipment with (1) plasma torch and (2) oxy/fuel torches, true – hole plasma burn technology. (Plasma burning capacities through 2 1/2″ thick. Oxy/fuel cutting capacities through 4″ thick). Cut dimensions 13′ 3″ wide x 78′ long on hydraulic lift water table.
- (1) 2005 Alltra Duel Plasma burning equipment and 12′ 3″ x 40′ cutting dimensions on water table. System includes one (1) straight plasma torch burning up to 1 1/2″ thick.
|
THICKNESS |
WIDTH |
LENGTH |
HOLE SIZE |
| Flame cutting |
(max) 8″ |
(max) 10′ |
(max) 40′ |
(min)3/4″ |
| Plasma cutting |
(max) 2″ |
(max) 14′ 2″ |
(max) 40′ |
(min)3/16″ |
BEVELING EQUIPMENT
- (2) Gullco portable plate bevellers
- (2) Challenger portable plate bevellers
- (4) Trumpf handheld beveling machines
- (1) Plate edge beveler, Baldwin 12′ x 40′
- (1) Plate edge beveler, Hills & Jones 12′ x 40′
|
MINIMUM |
MAXIMUM |
| Gullco |
3/8″ |
1 1/4″ |
| Hand beveler |
1/4″ |
1/2″ |
| Flame beveling |
1/2″ |
4″ |
| Plate edge bevellers |
1/4″ |
(max) 14′ 2″ |
PLATE ROLL
- (1) DAVI MCB 4080 hydraulic drive 4-roll pre-bending machine (Capacity 2″ thick x 12′ wide)
- (1) MCB K30 hydraulic drive 4-roll pre-bending machine (1 3/4″ x 9′ 8″)
- (1) DAVI 4-roll double initial pinch plate rolls (1 1/2″ x 10′ wide)
- (1) WEBB 3-roll slip bending machine (1/2″ x 6′)
Plate roll specs
|
THICKNESS |
WIDTH |
LENGTH |
HOLE SIZE |
| DAVI rolls |
1/4″ / 3″ |
N/A / 144″ |
40′ |
30″ / 32″ |
| Medium rolls |
10 GA / 5/8″ |
N/A / 8′ |
40′ |
40′ |
| Small rolls |
12 GA / 1/4″ |
N/A / 72″ |
40′ |
8″ / 8″ |
TURNING ROLLS
- (10) Turning rolls with idlers (total turning capacity 15’-0” O.D. and 120,000#). 1-60 ton power rolls with idlers 5-10 ton power rolls with idlers 2-30 ton power rolls with idlers 1-5 ton power rolls with idlers Turning rolls: 120,000# 2-80 ton power rolls with idlers
CRANES
- (1) 40 ton overhead top running crane with a 100’ wide span x 675’ long.
- (1) 10 ton overhead top running crane with a 100’ wide span; this crane is outside the seal bay and supplies material to the saws.
- (5) 10 ton overhead top running crane with a 96’-1” wide span; these cranes are in the fab bays (40’ hook height).
- (6) 15 ton overhead top running crane with a 56’-7” wide span; these cranes are in shell plate bays 1 and 2
(40’ hook height).
- (2) 25 ton overhead top running crane with a 56’-7” wide span; these cranes are in shell plate bays 1 and 2
(40’ hook height).
- (1) 25 ton Gantry crane with a 40’-0” wide span; this crane will run along a set of rails that are 725’-0” (25’ hook height).
- (2) 25 ton overhead top running crane with a 56’-7” wide span; these cranes are in non-AST bay (40’ hook height)
DRILL PRESSES
- (1) HASS CNC router drill
- (1) 36” radial arm drill press
- (6) Magnetic drills; (2) regular and (2) rotobroach
DRILL PRESS SPECS
| Carbon steel: |
|
| Thickness |
Hole Size |
| (min) 18 GA |
(min) 5/32” |
| (max) 4” |
(max) 2” |
POSITIONERS
- (1) Pinwheel, Ransome 30P
- (1) Pinwheel, Aronson (10,000#)
- (1) Large pinwheel (4,000#)
- (3) Large pinwheels (2,000#)
- (1) Tabletop pinwheel (500#)
WELDING MACHINES
- (3) Sub-arc large manipulators; (1) 1,000 amp AC/DC; (2) 600 amp
- (65) Mig, flux core, arc gouge, TIG and general purpose applications
- (9) Welders with pulse capability
- (1) Automated concepts robotic welder dual wire feed
| Automatic weld: |
|
|
| Thickness |
Length |
Diameter |
| (min) 1/4” |
(min) NA |
(min) 36” |
TORCH CUTTING SUPPLY
- Bulk argon/CO2
- Bulk nitrogen
- Bulk oxygen and NGL with header and drops at various locations
MANIPULATORS
- (3) Preston-Eastin MA-1414 SHD, 20’-0” X-axis, 19’-0” Y-axis
AUTOMATIC WELDERS
- (2) Lincoln DC-1000 Power Source, NA-3 sub-arc head, and control
- (4) Bug-O weld tractors
ALR ARC HEAD
- (3) ArcAir N6000 torch system with a remote control pendant
MANLIFT
HYDRAULIC TABLES
- (2) Hydraulic lift tables
